| Transport Dimensions by End Idler & Boom Combinations |
| Length with 40" (101.6 cm) End Idler and 14 ft (4.27 m) Boom (with Restraint Bar) |
41 ft (12.5 m) |
| Length with 50" (127 cm) End Idler and 12 ft (3.66 m) Boom |
40.8 ft (12.4 m) |
| Length with 40" (101.6 cm) End Idler and 12 ft (3.66 m) Boom |
39.7 ft (12.1 m) |
| Length with 50" (127 cm) End Idler and 10 ft (3.05 m) Boom |
38.3 ft (11.7 m) |
| Length with 40" (101.6 cm) End Idler and 10 ft (3.05 m) Boom |
37.2 ft (11.3 m) |
| Length with 50" (127 cm) End Idler and 8 ft (2.44 m) Boom |
35.8 ft (10.9 m) |
| Length with 40" (101.6 cm) End Idler and 8 ft (2.44 m) Boom |
34.7 ft (10.6 m) |
| Length with 40" (101.6 cm) End Idler and 6 ft (1.83 m) Boom |
32.2 ft (9.8 m) |
| Tracks & Ground Performance |
| Track Length |
176 in (447 cm) |
| Ground Pressure Maximum |
13.9 psi (95.8 kPa) |
| Ground Pressure Minimum |
9.4 psi (64.8 kPa) |
| Maximum Ground Speed - Low |
57.1 ft/min (17.4 m/min) |
| Maximum Ground Speed - High |
114 ft/min (34.7 m/min) |
| Conveyor System |
| Belt Width |
30 in (76.2 cm) |
| Engine Options |
| Gross Horsepower (Option One & Two) |
415 hp (309.5 kw) |
| Fuel Consumption at Full Load (Option One) |
20.9 gph (79.1 lph) |
| Fuel Consumption at Full Load (Option Two) |
21.3 gph (80.6 lph) |
| Fuel Tank Capacity (Option One & Two) |
184 gal (696.5 L) |
| Hydraulic Subsystem |
| Pump Flow at Maximum RPM |
27.9 gpm (105.6 L/min) |
| Pressure Setting |
2500 psi (172.4 bar) |
| Oil Tank Capacity |
152 gal (575.4 L) |
