| Transport Dimensions by Boom Length with 50" (127 cm) End Idler |
| Length with 16 ft (4.88 m) Boom (with Restraint Bar) |
45.3 ft (13.8 m) |
| Length with 14 ft (4.27 m) Boom (with Restraint Bar) |
43 ft (13.1 m) |
| Length with 12 ft (3.66 m) Boom |
42.3 ft (12.9 m) |
| Length with 10 ft (3.05 m) Boom |
39.8 ft (12.1 m) |
| Length with 8 ft (2.44 m) Boom |
37.3 ft (11.4 m) |
| Tracks & Ground Performance |
| Track Length |
177.5 in (450.9 cm) |
| Ground Pressure Maximum |
17.3 psi (119.3 kPa) |
| Ground Pressure Minimum |
13 psi (89.6 kPa) |
| Maximum Ground Speed - Low |
50 ft/min (15.2 m/min) |
| Maximum Ground Speed - High |
133 ft/min (40.5 m/min) |
| Conveyor System |
| Belt Width |
30 in (76.2 cm) |
| Engine Options |
| Gross Horsepower (Option One & Two) |
540 hp (402.7 kw) |
| Fuel Consumption at Full Load (Option One) |
28.9 gph (109.4 lph) |
| Fuel Consumption at Full Load (Option Two) |
28.1 gph (106.4 lph) |
| Fuel Tank Capacity (Option One & Two) |
270 gal (1022.1 L) |
| Hydraulic Subsystem |
| Pump Flow at Maximum RPM |
27.9 gpm (105.6 L/min) |
| Pressure Setting |
2500 psi (172.4 bar) |
| Oil Tank Capacity |
152 gal (575.4 L) |
