| Transport Dimensions by Boom Length with 50" (127 cm) End Idler |
| Length with 18 ft (5.49 m) Boom (with Restraint Bar) |
53.8 ft (16.4 m) |
| Length with 16 ft (4.88 m) Boom (with Restraint Bar) |
51.3 ft (15.6 m) |
| Length with 14 ft (4.27 m) Boom (with Restraint Bar) |
48.8 ft (14.9 m) |
| Length with 12 ft (3.66 m) Boom |
48 ft (14.6 m) |
| Length with 10 ft (3.05 m) Boom |
45.5 ft (13.9 m) |
| Length with 8 ft (2.44 m) Boom |
43 ft (13.1 m) |
| Tracks & Ground Performance |
| Track Length |
181.5 in (461 cm) |
| Ground Pressure Maximum |
21.1 psi (145.5 kPa) |
| Ground Pressure Minimum |
15.5 psi (106.9 kPa) |
| Maximum Ground Speed - Low |
44.2 ft/min (13.5 m/min) |
| Maximum Ground Speed - High |
118 ft/min (36 m/min) |
| Conveyor System |
| Belt Width |
36 in (91.4 cm) |
| Engine Options |
| Gross Horsepower (Option One & Two) |
600 hp (447.4 kw) |
| Fuel Consumption at Full Load (Option One) |
31.8 gph (120.4 lph) |
| Fuel Consumption at Full Load (Option Two) |
30.5 gph (115.5 lph) |
| Fuel Tank Capacity (Option One & Two) |
370 gal (1,400.6 L) |
| Hydraulic Subsystem |
| Pump Flow at Maximum RPM |
27.9 gpm (105.6 L/min) |
| Pressure Setting |
2500 psi (172.4 bar) |
| Oil Tank Capacity |
210 gal (794.9 L) |
