| Transport Dimensions by Boom Length with 40" (101.6 cm) End Idler |
| Length with 10 ft (3.05 m) Boom |
33.6 ft (10.2 m) |
| Length with 8 ft (2.44 m) Boom |
31.3 ft (9.5 m) |
| Length with 6 ft (1.83 m) Boom |
29.1 ft (8.9 m) |
| Length with 5 ft (1.52 m) Boom |
28 ft (8.5 m) |
| Tracks & Ground Performance |
| Track Length |
142 in (360.7 cm) |
| Ground Pressure Maximum |
12.5 psi (86.2 kPa) |
| Ground Pressure Minimum |
8.9 psi (61.4 kPa) |
| Maximum Ground Speed - Low |
85.2 ft/min (26 m/min) |
| Maximum Ground Speed - High |
170 ft/min (51.8 m/min) |
| Conveyor System |
| Belt Width |
24 in (61 cm) |
| Engine Options |
| Gross Horsepower (Option One & Two) |
275 hp (205.1 kw) |
| Fuel Consumption at Full Load (Option One) |
14.7 gph (55.6 lph) |
| Fuel Consumption at Full Load (Option Two) |
13.2 gph (50 lph) |
| Fuel Tank Capacity (Option One & Two) |
145 gal (548.9 L) |
| Hydraulic Subsystem |
| Pump Flow at Maximum RPM |
25.1 gpm (95 L/min) |
| Pressure Setting |
2500 psi (172.4 bar) |
| Oil Tank Capacity |
114 gal (431.5 L) |
