| Heavy-Duty Trencher / Track Plow Technical Specifications (350 hp) | |
|---|---|
| Transport Dimensions by Boom Length with 40" (101.6 cm) End Idler | |
| Length with 12 ft (3.66 m) Boom | 40.3 ft (12.3 m) |
| Length with 10 ft (3.05 m) Boom | 37.8 ft (11.5 m) |
| Length with 8 ft (2.44 m) Boom | 35.3 ft (10.8 m) |
| Length with 6 ft (1.83 m) Boom | 32.8 ft (10 m) |
| Tracks & Ground Performance | |
| Track Length | 147 in (373.4 cm) |
| Ground Pressure Maximum | 16.4 psi (113.1 kPa) |
| Ground Pressure Minimum | 11 psi (75.8 kPa) |
| Maximum Ground Speed - Low | 106.3 ft/min (32.4 m/min) |
| Maximum Ground Speed - High | 213 ft/min (64.9 m/min) |
| Conveyor System | |
| Belt Width | 30 in (76.2 cm) |
| Engine Options (Option One & Option Two Specs) | |
| Gross Horsepower | 350 hp (261 kw) |
| Fuel Consumption at Full Load | 18.3 gph (69.3 lph) |
| Fuel Tank Capacity | 172 gal (651.1 L) |
| Hydraulic Subsystem | |
| Pump Flow at Maximum RPM | 30.2 gpm (114.5 L/min) |
| Pressure Setting | 2500 psi (172.4 bar) |
| Oil Tank Capacity | 145 gal (548.9 L) |
