| General Dimensions and Weights |
| Weight - Basic Tractor (Tracks) |
16160 lbs (7330.1 kg) |
| Weight - Basic Tractor (Rubber Tires) |
11580 lbs (5252.6 kg) |
| Weight - Cab Configuration (Tracks) |
17180 lbs (7792.7 kg) |
| Weight - Cab Configuration (Rubber Tires) |
12630 lbs (5728.9 kg) |
| Length (Basic Tractor, Tracks) |
12.4 ft (3.8 m) |
| Length (Basic Tractor, Rubber Tires) |
11.6 ft (3.5 m) |
| Width (Basic Tractor, Tracks) |
92.5 in (235 cm) |
| Width (Basic Tractor, Rubber Tires) |
87.5 in (222.3 cm) |
| Height (Cab/Basic Configuration) |
115 in (292.1 cm) |
| Ground Clearance (Tracks & Rubber Tires) |
13.5 in (34.3 cm) |
| Ground Pressure (Basic Tractor, Tracks Only) |
5.6 psi (0.4 bar) |
| Engine Performance |
| Gross Horsepower (Maximum) |
127 hp (94.7 kw) |
| Maximum Torque |
369 ft-lb (500.3 Nm) |
| Ground Drive & Speeds |
| Rubber Tires: Max Forward/Reverse Transport Speed (High) |
10.2 mph (16.4 km/h) |
| Rubber Tires: Max Forward/Reverse Creep Speed (Low) |
4.1 mph (6.6 km/h) |
| Tracks: Max Forward/Reverse Transport Speed (High) |
10.1 mph (16.3 km/h) |
| Tracks: Max Forward/Reverse Creep Speed (Low) |
4.4 mph (7.1 km/h) |
| Hydraulic System Specifications |
| Attachment Pump Capacity |
61.8 gpm (233.9 L/min) |
| Attachment Pump Relief Pressure |
5510 psi (379.9 bar) |
| Ground Drive Pump Capacity |
36.7 gpm (138.9 L/min) |
| Ground Drive Pump Relief Pressure |
6090 psi (419.9 bar) |
| Auxiliary Pump Capacity |
17.6 gpm (66.6 L/min) |
| Auxiliary Pump Relief Pressure |
2500 psi (172.4 bar) |
| Fluid Capacities |
| Fuel Tank |
44 gal (166.6 L) |
| Hydraulic System Total |
35.6 gal (134.8 L) |
| Hydraulic Tank |
31.6 gal (119.6 L) |
| Coolant Capacity |
4.9 gal (18.5 L) |
