| General Dimensions and Weights |
| Weight - Tractor with Open Cab |
20215 lbs (9169.4 kg) |
| Weight - Tractor with Closed Cab |
21165 lbs (9600.3 kg) |
| Length (Basic Tractor, Tracks) |
152 in (386.1 cm) |
| Width (Basic Tractor, Tracks) |
100.5 in (255.3 cm) |
| Height (With Four-Post ROPS / Cab) |
122 in (309.9 cm) |
| Ground Clearance (Tracks) |
20.5 in (52.1 cm) |
| Roll Over Protection Structure Rating (Open/Closed) |
40000 lbs (18143.7 kg) |
| Engine Performance (Options One & Two) |
| Gross Horsepower (Maximum) |
127 hp (94.7 kw) |
| Net Horsepower |
124 hp (92.5 kw) |
| Maximum Torque |
369 ft-lb (500.3 Nm) |
| Displacement |
220 cu-in (3.6 L) |
| Maximum Fuel Consumption |
6.9 gph (26.2 lph) |
| Ground Drive & Steering Diameters |
| Ground Pressure (Basic Tractor Only) |
14.7 psi (1 bar) |
| Outside Turning Diameter (Steel Tracks, Front Steer Only) |
57.5 ft (17.5 m) |
| Outside Turning Diameter (Steel Tracks, Front and Rear Steer) |
36.7 ft (11.2 m) |
| Maximum Forward/Reverse Transport Speed (High) |
7.1 mph (11.4 km/h) |
| Maximum Forward/Reverse Creep Speed (Low) |
3.9 mph (6.3 km/h) or 342 ft/min (104.2 m/min) |
| Hydraulic System Specifications |
| Attachment Pump Output (at Max Engine RPM) |
61.8 gpm (233.9 L/min) |
| Attachment Pump Relief Pressure |
5510 psi (379.9 bar) |
| Ground Drive Pump Output (at Max Engine RPM) |
36.7 gpm (138.9 L/min) |
| Auxiliary Pump Relief Pressure |
2500 psi (172.4 bar) |
| Fluid Capacities |
| Fuel Tank |
44 gal (166.6 L) |
| Hydraulic System Total |
35.6 gal (134.8 L) |
| Hydraulic Tank |
31.6 gal (119.6 L) |
| Engine Cooling System (Without Cab) |
4.2 gal (15.8 L) |
| Engine Cooling System (With Cab) |
4.9 gal (18.5 L) |
| Diesel Exhaust Fluid (DEF) Tank |
2.7 gal (10 L) |
| Engine Crankcase with Filter |
11.1 qt (10.5 L) |
